Models for the Shocker Sport marker (1997-2002).
Part: LS stock trigger
Formats:
Inventor 10 part (.ipt)
Inventor 10 part (.ipt)
Created by: Ydna
Description: Stock double triger, used between 2001-2002 with LS boards.
Description: Stock double triger, used between 2001-2002 with LS boards.
Part: Trigger pin
Formats:
ACIS SAT file (.sat)
ACIS SAT file (.sat)
Created by: Ydna
Description: Trigger pivot pin. Also used with classic Impulses.
Description: Trigger pivot pin. Also used with classic Impulses.
Part: Vertical feed body
Formats:
ACIS SAT file (.sat)
ACIS SAT file (.sat)
Created by: Ydna
Description: Model for a vertical feed body, modeled after a 2001-2002 style body with threaded feedneck. This is reasonably accurate but some features are missing (like solenoid porting). Most of the internal bores aren't accurate.
Description: Model for a vertical feed body, modeled after a 2001-2002 style body with threaded feedneck. This is reasonably accurate but some features are missing (like solenoid porting). Most of the internal bores aren't accurate.
Part: LS circuit housing
Formats:
ACIS SAT file (.sat)
ACIS SAT file (.sat)
Created by: Ydna
Description: Model for a circuit housing modeled after a 2001-2002 marker (includes features for the LS board).
Description: Model for a circuit housing modeled after a 2001-2002 marker (includes features for the LS board).
Part: LS frame
Formats:
ACIS SAT file (.sat)
ACIS SAT file (.sat)
Created by: Ydna
Description: Model for a grip frame modeled after a 2001-2002 marker. This file is very similar to the grip frame used in classic Impulses from the same year. Older Shocker grip frames were similar, but the biggest functional difference is that they used an angled trigger spring hole.
Description: Model for a grip frame modeled after a 2001-2002 marker. This file is very similar to the grip frame used in classic Impulses from the same year. Older Shocker grip frames were similar, but the biggest functional difference is that they used an angled trigger spring hole.
Part: LS board
Formats:
ACIS SAT file (.sat)
ACIS SAT file (.sat)
Created by: Ydna
Description: Circuit board assembly for the LS style board. This includes the trigger microswitch hanging off the bottom. No front-mounted switch included.
Description: Circuit board assembly for the LS style board. This includes the trigger microswitch hanging off the bottom. No front-mounted switch included.
Part: LS board switch actuator
Formats:
ACIS SAT file (.sat)
ACIS SAT file (.sat)
Created by: Ydna
Description: This small plastic slide switch actuator is used with LS boards.
Description: This small plastic slide switch actuator is used with LS boards.
Part: Bolt assembly 2002
Formats:
ACIS SAT file (.sat)
ACIS SAT file (.sat)
Created by: Ydna
Description: This file contains all the internals for a bolt piston assembly, based on parts from a 2002 marker. The main difference between these and older parts is the addition of an allen key hex rather than a screwdriver. Note that the bolt housing has knurling modeled directly into the part, which is mostly a visual element. No threads are modeled into these components.
Description: This file contains all the internals for a bolt piston assembly, based on parts from a 2002 marker. The main difference between these and older parts is the addition of an allen key hex rather than a screwdriver. Note that the bolt housing has knurling modeled directly into the part, which is mostly a visual element. No threads are modeled into these components.
Part: Fire piston housing (1998 series)
Formats:
Inventor 10 part (.ipt)
Inventor 10 part (.ipt)
Created by: Ydna
Description: Stock fire piston housing with the flathead screwdriver slot for removal (used between 1998-2000).
Description: Stock fire piston housing with the flathead screwdriver slot for removal (used between 1998-2000).
Part: Gadget grip assembly
Formats:
ACIS SAT file (.sat)
ACIS SAT file (.sat)
Created by: Ydna
Description: Assembly file for the gadget grip. This includes the main handle, barrel plug, and the threaded stud (1 inch long).
Description: Assembly file for the gadget grip. This includes the main handle, barrel plug, and the threaded stud (1 inch long).
Common parts:
Check the CAD file post index for links to universal parts which are compatible between multiple markers. This may include feednecks, regulators, air fittings, solenoids, and others.
